The Magic FIR

Admin:   Add Time: 2017-10-30

Like the pit viper, get access to thethermal world around you with the MLX90640.


MLX90640-- Addresses growingdemands seen across numerous applications for thermal analysis. The sensor provides enhanced resolution while still occupyingan attractive price point. Primary applications for this device include people detection, fire prevention,building automation, lighting control, surveillance and air conditioningsystems.


KEY FEATURES



Ø-40°Cto 85°C operational temperature

range,allows deployment in difficult industrial

environments

ØCan measure object temperaturesbetween -40°C

and300°C

ØA typicaltarget object temperature accuracy of

±1°C,precision across its full measurement scale

ØNoise equivalent temperature difference(NETD)

ofjust 0.1K RMS at a 1Hz refresh rate, offers

superiornoise performance

ØUnlike microbolometer solutions, this sensor does

notneed re-calibration to specific temperature

requirementsensuring greater convenience and

loweringoperational expense

ØTwo different field of view (FoV)options - standard

55°x35°version and a 110°x75° wide angle version

ØSupplied in a 4-pin TO39 package, with the

compactdimensions lowering the overall cost of

thethermal imaging system

ØI2Ccompatible digital interface,

simplifyingintegration
